Anti Vandal Metal Momentary Push Button Switch 22mm Ring Symbol LED 5A 250V AC

Yueqing Yueshun Electric Co., Ltd.
Contact Now

Anti Vandal Metal Momentary Push Button Switch 22mm Ring Symbol LED 5A 250V AC

  • 1
  • 2
  • 3

Brand Name : YUESHUN

Model Number : JS22F-11E/S

Certification : CE RoHS

Place of Origin : Wenzhou, China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T to our company account or by paypal

Supply Ability : 5000Pcs/Day

Delivery Time : 3-7 work days

Packaging Details : The product is packed in foam box to prevent damage during transportation.

Led Type : Ring Symbol

LED life : More than 40,000 hours

Terminal material : Silver alloy

Panel mounting : 22mm

Protection Level : IP 67

Mechanical life : More than1,000,000 cycles

Contact Now

22mm Ring symbol led Anti Vandal Push Button Switch 5A 250V AC Metal momentary push button switch



Product Description

- Yueshun push button switches brings you a wide range of high-quality and high cost performance. Our products has been rigorously tested against demanding industry standard. You can trust us.
- Our push button switches are tested rigorously. Each piece is tested for appearance and clicking for at least 5 times before sending .
- Latching switch, push it down, it stays down and latched in the closed position, press the button again and it releases and unlatched;

- Momentary switches are switches which only remain in their on state as long as they’re being actuated (pressed, held, etc.).



Product Specification

  Model Number   JS22F-11E/S
  Mounting Hole   22mm
  Max.Switch Rating   Ith : 5A Ui : 250V AC
  Material   Body Material : Stainless Steel
  Button Material : Stainless Steel
  Contact Material : Silver Alloy
  Base Material : PBT
  The Front Shape   Flat Round Head
  Terminal Type   Pin Termlmal( 2.8 * 0.5 MM )
  Switch Operation   Momentary or Latching are available
  Contact Configuration   1NO + 1NC or 2NO + 2NC
  Mounting panel thickness   Momentary 1-8 mm , Latching 1-13mm
  Operation Distance   About 0.5 mm
  LED Parameters   Led Type : Ring Symbol
  LED Color :
  Red,Green,Yellow,Orange,Blue,White,Purple or Double color mixing all Can be customized.
  Led Voltage:
3V 6V 12V 24V 36V 110V 220V 360V for choose.
  LED Life : More than 40,000 hours
  Protection Level   IP67
  Operating Temp

  -20℃~+55℃



Anti Vandal Metal Momentary Push Button Switch 22mm Ring Symbol LED 5A 250V AC
